3939Radiator

Radiator

CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road

  • OEM specified Plastic Tank-Aluminum Core Construction
  • Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
  • Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120°F
  • Tubes - Welded Type or Latest Generation "B-Tube" Design
  • Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
  • 100% leak tested before leaving factory at 150% of operating pressure
  • Industry Best Packaging - "10 Foot Drop Test" Standard
  • Drop-in Fit
  • High Performance Transmission Cooler with special Built-in Turburlator, when applicable
  • All components are installed, torqued, & tested on Radiator during assembly
Bottom Hose Fitting (in): 1 3/8 Right
Box Height (in): 6 1/4
Box Length (in): 33 13/16
Box Weight (lbs): 11
Box Width (in): 24 3/4
Core Length (in): 26 1/2
Core Material: Aluminum
Core Thickness (in): 7/8
Core Width (in): 21
Cross-flow/ Down-flow: Cross Flow
Hazardous Material: No
Inlet Length (in): 21 3/4
Inlet Width (in): 1 5/8
No. Of Rows: 1
Oil Cooler (in): No
Outlet Length (in): 21 3/4
Outlet Width (in): 1 5/8
Radiator Cap Supplied: No
Tank Material: Plastic
Tech Note: O.E.M. style Plastic tank & Aluminum core.
Top Hose Fitting (in): 1 3/8 Left
Make Model Qualifiers Year
Ford Escape
  • Position: N/A
  • 1.5L L3 1497cc 91ci
  • Turbocharged
 2020-2023
Ford Escape
  • Position: N/A
  • 2.0L L4 1999cc 122ci
  • Turbocharged
 2020-2023
Ford Escape
  • Position: N/A
  • 2.5L L4 2488cc 152ci
  • FULL HYBRID EV-GAS (FHEV)
 2020-2023
Ford Escape
  • Position: N/A
  • 2.5L L4 2488cc 152ci
  • PLUG-IN HYBRID EV-GAS (PHEV)
 2020-2023
Ford Maverick
  • Position: N/A
  • 2.0L L4 1999cc 122ci
  • Turbocharged
 2022-2023
Lincoln Corsair
  • Position: N/A
  • 2.0L L4 1999cc 122ci
  • Turbocharged
 2020-2023
Lincoln Corsair
  • Position: N/A
  • 2.3L L4 2300cc 140ci
  • Turbocharged
 2020-2023
Lincoln Corsair
  • Position: N/A
  • 2.5L L4 2488cc 152ci
  • PLUG-IN HYBRID EV-GAS (PHEV)
 2021-2023

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference NumberReference Name
13850DPI
13901DPI
FO3010369Partslink
LX6Z 8005 AOEM
LX6Z 8005 BOEM
LX6Z 8005 FOEM
LX6Z 8005 HOEM
LX6Z 8005 LOEM
LX6Z 8005 MOEM
LX6Z 8005 QOEM
MX6Z 8005 BOEM
