CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road
Bottom Hose Fitting (in): 1 3/8 Right
Box Height (in): 4 11/16
Box Length (in): 32 13/16
Box Weight (lbs): 8
Box Width (in): 22 3/16
Core Length (in): 26 9/16
Core Material: Aluminum
Core Thickness (in): 5/8
Core Width (in): 18 5/16
Cross-flow/ Down-flow: Cross Flow
Hazardous Material: No
Inlet Length (in): 19
Inlet Width (in): 1 9/16
No. Of Rows: 1
Oil Cooler (in): No
Outlet Length (in): 19
Outlet Width (in): 1 9/16
Radiator Cap Supplied: No
Tank Material: Plastic
Tech Note: O.E.M. style Plastic tank & Aluminum core with quick-connect inlet & outlet pipe.
Top Hose Fitting (in): 1 3/8 Left
Make Model Qualifiers Year
Hyundai Sonata
  • Position: N/A
  • 2.5L L4 2497cc

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference NumberReference Name
