3931Radiator

Radiator

CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road
Bottom Hose Fitting (in): 1 3/8 Right (in)
Box Height (in): 5 1/16
Box Length (in): 24 9/16
Box Weight (lbs): 8
Box Width (in): 22 3/8
Core Length (in): 18 11/16 (in)
Core Material: Aluminum
Core Thickness (in): 1 1/4 (in)
Core Width (in): 18 5/16 (in)
Cross-flow/ Down-flow: Cross Flow
Hazardous Material: No
Inlet Length (in): 19
Inlet Width (in): 1 9/16
No. Of Rows: 1
Oil Cooler (in): No
Outlet Length (in): 19
Outlet Width (in): 1 9/16
Radiator Cap Supplied: No
Tank Material: Plastic
Tech Note: O.E.M. style Plastic tank & Aluminum core with quick-connect inlet & outlet pipe.
Top Hose Fitting (in): 1 3/8 Left (in)
Make Model Qualifiers Year
Hyundai Sonata
  • Position: N/A
  • 1.6L L4 1598cc 98ci
  • Turbocharged
 2020-2022

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference NumberReference Name
13854DPI
25310-L0000OEM
HY3010226Partslink
