3662Radiator
1 Row Plastic Tank Aluminum Core

Radiator

CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road

  • OEM specified Plastic Tank-Aluminum Core Construction
  • Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
  • Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
  • Tubes - Welded Type or Latest Generation "B-Tube" Design
  • Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
  • 100% leak tested before leaving factory at 150% of operating pressure
  • Industry Best Packaging - "10 Foot Drop Test" Standard
  • Drop-in Fit
  • High Performance Transmission Cooler with special Built-in Turburlator, when applicable
  • All components are installed, torqued, & tested on Radiator during assembly
Bottom Hose Fitting (in): 1 3/4 Right (in)
Box Height (in): 8 1/16
Box Length (in): 38 3/4
Box Weight (lbs): 15
Box Width (in): 25 11/16
Core Length (in): 27 1/2 (in)
Core Material: Aluminum
Core Thickness (in): 1 1/4 (in)
Core Width (in): 21 9/16 (in)
Cross-flow/ Down-flow: Cross Flow
Csf Cap Number: 4515
Hazardous Material: No
Inlet Length (in): 22 11/16
Inlet Width (in): 1 5/8
No. Of Rows: 1
Outlet Length (in): 22 11/16
Outlet Width (in): 1 5/8
Radiator Cap Supplied: No
Tank Material: Plastic
Tech Note: O.E.M. style Plastic tanks & Aluminum core. Upgraded Heavy Duty Core. 11% Thicker 30mm vs OEM 27mm
Top Hose Fitting (in): 1 1/2 Left (in)
Make Model Qualifiers Year
Dodge Ram 1500
  • Position: N/A
  • 4.7L V8 287ci
 2009-2010
Dodge Ram 1500
  • Position: N/A
  • 3.7L V6 226ci
 2009-2010
Dodge Ram 1500
  • Position: N/A
  • 5.7L V8 345ci
 2009-2010
Dodge Ram 2500
  • Position: N/A
  • 5.7L V8 345ci
 2010
Ram 1500
  • Position: N/A
  • 5.7L V8 345ci
 2011-2018
Ram 1500
  • Position: N/A
  • 4.7L V8 287ci
 2011-2013
Ram 1500
  • Position: N/A
  • 3.6L V6 3604cc 220ci
 2013-2018
Ram 1500
  • Position: N/A
  • 3.7L V6 226ci
 2011-2012
Ram 1500
  • Position: N/A
  • 3.6L V6 3600cc 220ci
 2014-2016
Ram 1500 Classic
  • Position: N/A
  • 3.6L V6 3604cc 220ci
 2019-2021
Ram 1500 Classic
  • Position: N/A
  • 5.7L V8 345ci
 2019-2021
Ram 2500
  • Position: N/A
  • 5.7L V8 345ci
 2011-2013
Ram 3500
  • Position: N/A
  • 5.7L V8 345ci
 2013

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference NumberReference Name
13129DPI
13294DPI
13295DPI
55056858 ADOEM
55056858 AEOEM
55056870 AEOEM
55056870 AFOEM
55057090 ABOEM
55057090ACOEM
8013129APDI
CH3010353Partslink
CH3010354Partslink
CU13129SPI
